Our capability includes:
Materials Machined:
- Stainless Steel, Alloy Steel, Tool Steel, Carbon Steels, Inconel, Monel, Hastelloy, Titanium, Niron, A286, Aluminum, Copper, Bronze, Beryllium, Brass, most exotic metals, and many plastics.
CNC Swiss Lathes: (Tolerance = + 0.0001”)
- 7 Star, SR-20 mm dia. capacity, bar feed, 7-axis live tooling
- 6 Star, SW-12 mm dia. capacity, bar feed, 10-axis live tooling
- 2 Star, SR-38 mm dia. capacity, bar feed, 10-axis live tooling
- 4 Star, SW-20 mm dia. capacity, bar feed, 11-axis live tooling
- 3 Star, SV-20 mm dia. capacity, bar feed, 12-axis live tooling
CNC Turn/Mill Lathes: (Tolerance = + 0.0002”)
- 3 Nakamuras, WT-150 turning centers, 20 hp, 2” dia. bar feed, 7-axis, Twin Turret, Twin Spindle
- 1 Haas CL1 chucking lathe
CNC Mills: (Tolerance = + 0.0001”)
- 3 Makinos, 3-axis milling centers, 30 hp, 30-tool turrets, Travel 35” x 20” x 17”, Milling size = 24” x 18” x 12”
CMM: Zeiss 28” cubic capacity, Micro-View Vision 24” x 24” x 6”, 2 Starrett AVR300 Vision Automatic Video Metrology Systems.
Secondary processes include assembly, heat-treating, and grinding. |
Typical Products: Clamps, pins, bushings, thumbscrews, jackscrews, standoffs, fasteners, brackets, bearings, washers, valves, spacers, couplings, bolts, joints, shafts, sleeves, nuts, pulleys, rivets, and most small hardware.
Precision: (Tolerance per lineal inch)
CNC Turning = .0003" CNC Screw Machining = .0002" CNC Milling = .0005" CNC Teaming = .0003" Centerless Grinding = .0002" ID Honing = .00003" Surface Finish = 4 Micro |
 |
